156

Operations Conditions:
Temperature:-20℃ to +120℃
Pressure:≤1.0MPa
Speed:≤10m/s

Materials:
Stationary Ring: Silicon Carbide Reaction Bonded, Ceramic(Alumina), Silicon Carbide Sintered Pressureless, Ni-binder Tungsten Carbide
Rotary Ring: Antimony Impreg. Carbon Graphite, Resin Impregnated Carbon Graphite(Furan), Silicon Carbide Reaction Bonded, Silicon Carbide Sintered Pressureless, Ni-binder Tungsten Carbide
Secondary Seal: Fluorocarbon Rubber(Viton), Nitrile(NBR),Ethylene Propylene(EPDM),
Spring and Metal Parts: Stainless Steel, Stainless Steel

Applications：Clean Water,Sewage Water,Oil and other moderately corrosive fluids.
